LINIO NEON 1617 RGBWW (IP67)

248 lm/ft·RGBWW


- Robust & uniform silicone body, changeable RGBWW colors

- IP67 rated, ideal for outdoor uses

- 5 years warranty


Inquiry
Download
Spec Sheet - LINIO NEON 1617 RGBWW(Rev.01-Dec-2025)
IES - LINIO NEON 1617 RGBWW
Specify your products
Product Code:
-
W7
-
24
-
RGBWW2755
-
527
-
-
-
-
-
-
Copy
Reset
1. Series
LN1617TV
LN1617SV
2. Environment
W7-Wet (IP67)
3. Voltage
24-DC24V
4. CCT
RGBWW2755-RGBWW (WW=2700K+5500K)
5. Power
527-5.27W
6. End Cap
IJ-Injected end cap (IP67)
IJC-Clear injected end cap (IP67)
SEC-Silicone end cap (IP67)
MEC1-Mechanical end cap with screws (IP67)
7. Left Feed Entry (A)
F-Front
B-Bottom
S-Side
C-Closed
8. Left Feed Entry (B)
OW-Open wire 3.28'
MC-Male connector with 0.98' cable
FC-Female connector with 0.98' cable
NA-Only for Closed Feed Entry
9. Right Feed Entry (A)
F-Front
B-Bottom
S-Side
C-Closed
10. Right Feed Entry (B)
OW-Open wire 3.28'
MC-Male connector with 0.98' cable
FC-Female connector with 0.98' cable
NA-Only for Closed Feed Entry
11. Length (ft)
* Customizable—Consult Factory
Technical specifications

Series: LN1617TV / LN1617SV

Compatible power supplies
KVX Series (DMX512 Dimming)
KVX Series (DMX512 Dimming)

96W/150W/200W/300W, UL-listed, 24V


• Dimming options: DMX512

• Constant Voltage Driver

• Input Voltage: 100-277VAC

• Slightly adjustable output voltage

• Built-in active PFC

• RDM (Remote Device Management)

• Protection: short circuit/over load/over heat

• Dry/damp/wet locations

• Flicker-free

• 0-100% dimmable

• Read and write DMX512 address or fine-tune output voltage with mobile ProNFC app or special NFC device
KV Series (Non Dimming)
KV Series (Non Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• Non-dimmable

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Protection: short circuit/over load/over heat
Compatible DMX decoders and control
Ltech DMX Decoder (RGBW)
Ltech DMX Decoder (RGBW)

RGBW, UL-recognized
Nicolaudie Stick CW4
Nicolaudie Stick CW4

1024 channels, WIFI, APP, time clock
Compatible accessories
Silicone Front End Cap
Silicone Front End Cap

Glue installation
Silicone Side End Cap
Silicone Side End Cap

Glue installation
Silicone Bottom End Cap
Silicone Bottom End Cap

Glue installation
Silicone Closed End Cap
Silicone Closed End Cap

Glue installation
Mechanical Right Side End Cap
Mechanical Right Side End Cap

DIY, with screws
Mechanical Bottom End Cap
Mechanical Bottom End Cap

DIY, with screws
Mechanical Closed End Cap
Mechanical Closed End Cap

DIY, with screws
Mechanical Front End Cap
Mechanical Front End Cap

DIY, with screws
Mechanical Left Side End Cap
Mechanical Left Side End Cap

DIY, with screws
