Home Products Side Bend LINIO NEON 0408X SV TW (IP65)
/
LINIO NEON 0408X SV TW (IP65)

50 lumen outputs·Tunable white


▪  Ultra-slim form factor

▪  Field cuttable & joinable

▪  Low voltage DC24V

▪  50 lumen outputs

▪  IP65 rated, ideal for indoor uses

▪  5 years warranty


Inquiry
Download
Spec Sheet - LINIO NEON 0408X SV TW (Rev24-Apr-25)
IES - LINIO NEON 0408X SV TW
Install Manual - LINIO NEON 0408 SV SERIES (Rev.2024-10-15) - US
Specify your products
Product Code:
LN0408XSV
-
W5
-
24
-
2760
-
183
-
-
-
-
-
-
Copy
Reset
1. Series
LN0408XSV
2. Environment
W5-Wet (IP65)
3. Voltage
24-DC24V
4. Temp./Color
2760-2700K+6000K
5. Power
183-1.83W
6. End Cap
IJ-Injected end cap (IP54)
IJC-Clear injected end cap (IP54)
SEC-Silicone end cap (IP65)
7. Left Feed Entry (A)
F-Front
C-Closed
8. Left Feed Entry (B)
OW-Open wire 3.28'
MC-Male connector with 0.98' cable
FC-Female connector with 0.98' cable
NA-Only for Closed Feed Entry
9. Right Feed Entry (A)
F-Front
C-Closed
10. Right Feed Entry (B)
OW-Open wire 3.28'
MC-Male connector with 0.98' cable
FC-Female connector with 0.98' cable
NA-Only for Closed Feed Entry
11. Length (ft)
* Customizable—Consult Factory
Technical specifications

Series: LN0408XSV


Temp./Color

1.83W/ft

2700K

49

6000K

50

2700K+6000K

49


Compatible drivers
KVD Series (0-10V Dimming)
KVD Series (0-10V Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• Dimming options: 0-10V/1-10V/Potentiometer/10V PWM

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Built-in active PFC

• Protection: short circuit/over load/over heat

• 0-100% dimmable with dimmer
KVG Series (Triac/0-10V Dimming)
KVG Series (Triac/0-10V Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• 5 in 1 dimmable: Triac/0-10V/1-10V/Potentiometer/10V PWM

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Protection: short circuit/over load/over heat
KVF Series (Phase cut/Triac Dimming)
KVF Series (Phase cut/Triac Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• Dimming options: Triac/Phase/ELV/MLV

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Load: 10-100%

• Protection: short circuit/over load/over heat

• Flicker-free
KV Series (Non Dimming)
KV Series (Non Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• Non-dimmable

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Protection: short circuit/over load/over heat
Compatible accessories
Silicone Front End Cap
Silicone Front End Cap

Glue installation
Silicone Closed End Cap
Silicone Closed End Cap

Glue installation
