Home Products 360° LINIO NEON 360° RGBW (IP65)
/
LINIO NEON 360° RGBW (IP65)

100 lumen outputs · RGBW



▪  360° emitting provides unparalleled creativeness

▪  Factory assembly

▪  Low voltage DC24V

▪  100 lumen outputs

▪  IP65 rated, ideal for indoor uses

▪  5 years warranty





Inquiry
Download
Spec Sheet - LINIO NEON 360° RGBW (Rev.23-Apr-25)
Install Guide - LINIO NEON 360° RGBW (Rev.2023-07-20)
Specify your products
Product Code:
LN360
-
W5
-
24
-
-
488
-
IJ
-
-
-
-
-
Copy
Reset
1. Series
LN360
2. Environment
W5-Wet (IP65)
3. Voltage
24-DC24V
4. Temp./Color
RGBW22-RGBW (W=2200K)
RGBW27-RGBW (W=2700K)
RGBW30-RGBW (W=3000K)
RGBW35-RGBW (W=3500K)
RGBW40-RGBW (W=4000K)
RGBW45-RGBW (W=4500K)
5. Power
488-4.88W
6. End Cap
IJ-Injected end cap (IP65)
7. Left Feed Entry (A)
F-Front
S-Side
C-Closed
8. Left Feed Entry (B)
OW-Open wire 3.28'
MC-Male connector with 0.98' cable
FC-Female connector with 0.98' cable
NA-Only for Closed Feed Entry
9. Right Feed Entry (A)
F-Front
S-Side
C-Closed
10. Right Feed Entry (B)
OW-Open wire 3.28'
MC-Male connector with 0.98' cable
FC-Female connector with 0.98' cable
NA-Only for Closed Feed Entry
11. Length (ft)
* Customizable—Consult Factory
Technical specifications

Series: LN360


Temp./Color

4.88W/ft

R

14

G

44

B

8

W22

45

W27

50

W30

50

W35

51

W40

51

W45

51

RGBW22

110

RGBW27

113

RGBW30

113

RGBW35

114

RGBW40

114

RGBW45

114


Compatible drivers
KVX Series (DMX512 Dimming)
KVX Series (DMX512 Dimming)

96W/150W/200W/300W, UL-listed, 24V


• Dimming options: DMX512

• Constant Voltage Driver

• Input Voltage: 100-277VAC

• Slightly adjustable output voltage

• Built-in active PFC

• RDM (Remote Device Management)

• Protection: short circuit/over load/over heat

• Dry/damp/wet locations

• Flicker-free

• 0-100% dimmable

• Read and write DMX512 address or fine-tune output voltage with mobile ProNFC app or special NFC device
KV Series (Non Dimming)
KV Series (Non Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• Non-dimmable

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Protection: short circuit/over load/over heat
Compatible DMX decoders and control
Ltech DMX Decoder (Universal)
Ltech DMX Decoder (Universal)

Multi-channels, UL-recognized
Nicolaudie Stick CW4
Nicolaudie Stick CW4

1024 channels, WIFI, APP, time clock
